HAYNES 25 Sheets & Plates

Sunrise Industries is a prominent manufacturer and supplier of Haynes 25 Sheets and Plates in India. These products are engineered using a high-performance cobalt-based alloy that delivers superior mechanical strength and resistance to harsh environments. Haynes 25 Sheets and Plates are ideal for industries that demand reliable performance under high-temperature and corrosive conditions. With a focus on quality and precision, our range is produced in accordance with global standards and tailored to meet diverse industrial requirements.

Haynes 25, also recognized as UNS R30605 or Alloy L605, is a non-magnetic superalloy composed primarily of cobalt, nickel, chromium, and tungsten. It is known for its ability to retain strength at elevated temperatures and its excellent resistance to oxidation and corrosion. This material cannot be hardened through heat treatment but achieves significant hardness and strength through cold working. It can be hot forged, cold worked, or fabricated into a wide range of sheet and plate forms, making it highly versatile for industrial applications.

The defining characteristics of Haynes 25 Sheets and Plates include superior high-temperature strength and exceptional resistance to aggressive chemical environments such as hydrochloric acid, nitric acid, and wet chlorine. These properties make the alloy suitable for use in marine applications and even in contact with body fluids. The alloy also performs well in mechanically demanding environments, offering long-term durability and resistance to wear and fatigue. It is available in various finishes and forms including hot rolled, cold rolled, chequered, shim, and perforated sheets.

Haynes 25 Sheets and Plates are widely used in several high-stress industries. In the aerospace sector, they are employed in jet engine components such as turbine rings, combustion chambers, and afterburners. The medical industry utilizes this alloy in implantable devices like laser-welded balloon stents due to its biocompatibility and strength. In high-temperature furnace environments, it is used for making muffles, liners, and other critical parts. The alloy’s corrosion-resistant properties also make it suitable for equipment used in chemical processing and marine settings.

Sunrise Industries offers an extensive range of Haynes 25 Sheets and Plates in various specifications and dimensions to meet customer needs. Our product range includes hot rolled plates, cold rolled sheets, and customized industrial plates. We also provide specialty forms such as chequered, shim, and perforated sheets, all produced with precision and care. These products are available in both standard and custom sizes, ensuring that clients receive the right material for their specific applications.

Why Choose Haynes 25 Sheets & Plates from Sunrise Industries?

Manufactured using premium-grade cobalt-nickel-chromium-tungsten alloy for high strength
Excellent resistance to corrosion, oxidation, acids, and marine environments
Performs exceptionally well at elevated temperatures without losing integrity
Suitable for aerospace, medical, and furnace applications
Available in hot rolled, cold rolled, perforated, chequered, and shim forms
Custom sizes and dimensions available with safe, damage-free delivery across India

HAYNES 25 Sheets & Plates

Specification of Haynes 25 Sheets, Plates

Specifications:

AMS 5759, AMS 5537

Standard:

AMS, AMS, API

Thickness:

3mm-80mm

Width:

1.5mm to 1500mm

Specialize sheets, Plates :

Perforated Sheet, Chequered Plates

Size :

0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH

Form :

Plates, Sheets, Plain Sheet, Shim Sheet

Hardness :

Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc.

Grade:

HAYNES 25 UNS R30605

Haynes 25 Sheets, Plates Equivalent Grades
STANDARD	Material No	EN Designation	UNS	Alloy
Haynes 25	2.4964	CoCr20W15Ni	R30605	25

Haynes 25 Sheets, Plates Chemical Composition
Grade	C%	Si%	Mn%	P%	S%	Cr%	Ni%	Co%	Fe%	W%
Haynes 25	0.05–0.15	0.40	2.00	0.02	0.015	19.0–21.0	9.00–11.0	Rest	≤ 3.00	14.0–16.0

Haynes 25 Sheets, Plates Mechanical Properties
Grade	Yield Strength 0.2% Rp ≥ N/mm²	Tensile Strength Rm N/mm²	Elongation A5 %	Resistant on Air up to °C	Modulus of Elasticity kN/mm²
Haynes 25	345	830–1130	25	1090	225

Trusted Supplier for Bulk & Project-Based Orders

Whether you’re looking for large-volume procurement or project-specific quantities, we are well-equipped to fulfill orders with speed and accuracy. Our extensive inventory of Bright Bars is maintained in ready stock across multiple grades and finishes to ensure immediate dispatch. We also collaborate with engineering consultants, EPC contractors, and fabrication companies to supply Bright Bars for mega infrastructure and industrial projects. Strict quality checks and test certifications accompany every dispatch, reinforcing our commitment to excellence. From oil & gas pipelines to machinery components — our bars are built to perform under pressure.

Precision Engineered Bright Bars with Superior Surface Finish

Bright Bars are manufactured with meticulous attention to detail to achieve tight dimensional tolerances and a smooth, polished surface. These features make them ideal for applications that demand high accuracy, such as shafts, fasteners, tools, and precision components. Our bars are produced through controlled cold drawing and grinding processes that enhance their mechanical strength and improve machinability. With options ranging from black to mirror polish finishes, they meet both aesthetic and functional requirements. Each Bright Bar undergoes rigorous quality testing to ensure compliance with global engineering standards.
